Innomotics 1LE8044-2DB0 Cast Iron 75 kW IE4

Name: Innomotics 1LE8044-2DB0 Cast Iron 75 kW IE4
Brand: Innomotics
SKU: 1LE8044-2DB0
Availability: InStock

SKU: 1LE8044-2DB0

Flow Line Motors

Cast Iron Flow Line motor, 75 kW, IE4, 1490 rpm, frame 280 S

Rated Power

75 kW

Sound Pressure Level

66 dB(A)

Frame Size

280 S

Innomotics is part of Siemens Group. We respond to quote requests within 4 business hours.

Electrical

Rated Power	75 kW
Rated Speed	1490 rpm
Efficiency Class	IE4
Efficiency at 100% Load	96.0 %
Efficiency at 75% Load	96.3 %
Efficiency at 50% Load	96.1 %
Power Factor	0.87
Rated Current	481.0 A
Rated Torque	130.0 Nm
Starting Current Ratio (Ist/In)	8.5
Starting Torque Ratio (Tstart/Tn)	2.8
Maximum Torque Ratio (Tmax/Tn)	3.0

Environmental

Sound Pressure Level	66 dB(A)
Sound Power Level	80 dB(A)

Mechanical

Frame Size	280 S
Enclosure Material	Cast Iron
Weight	605 kg

Detailed Description

Innomotics 1LE8044-2DB0 Flow Line motor with cast iron enclosure. IE4 efficiency class, rated power 75 kW at 1490 rpm. Frame size 280 S. Efficiency 96.0% at full load. Rated current 481.0 A. Weight 605 kg.
