Innomotics 1LE8044-2DA0 Cast Iron 75 kW IE4

SKU: 1LE8044-2DA0
Flow Line Motors

Cast Iron Flow Line motor, 75 kW, IE4, 2978 rpm, frame 280 S

Rated Power
75 kW
Sound Pressure Level
75 dB(A)
Frame Size
280 S

Innomotics is part of Siemens Group. We respond to quote requests within 4 business hours.

Electrical

Rated Power 75 kW
Rated Speed 2978 rpm
Efficiency Class IE4
Efficiency at 100% Load 95.6 %
Efficiency at 75% Load 95.6 %
Efficiency at 50% Load 95.0 %
Power Factor 0.9
Rated Current 241.0 A
Rated Torque 126.0 Nm
Starting Current Ratio (Ist/In) 8.5
Starting Torque Ratio (Tstart/Tn) 2.8
Maximum Torque Ratio (Tmax/Tn) 3.2

Environmental

Sound Pressure Level 75 dB(A)
Sound Power Level 89 dB(A)

Mechanical

Frame Size 280 S
Enclosure Material Cast Iron
Weight 555 kg

Dimensions

Shaft height (H) 280 mm
Shaft diameter (D) 65 mm
Shaft length (E) 140 mm
Key width (F) 18 mm
Dimension over key (GA) 69 mm
Foot holes - across (A) 457 mm
Foot holes - along (B) 368 mm
Shaft shoulder to foot hole (C) 190 mm
Foot hole diameter (K) 24 mm
Overall width (AB) 540 mm
Overall diameter (AC) 551 mm
Centre to top of terminal box (AD) 433 mm
Overall length (L) 960 mm
Overall length incl. shaft (LC) 1105 mm

Detailed Description

Innomotics 1LE8044-2DA0 Flow Line motor with cast iron enclosure. IE4 efficiency class, rated power 75 kW at 2978 rpm. Frame size 280 S. Efficiency 95.6% at full load. Rated current 241.0 A. Weight 555 kg.
