Innomotics 1LE0043-1AC4 Cast Iron 1.5 kW IE3

Name: Innomotics 1LE0043-1AC4 Cast Iron 1.5 kW IE3
Brand: Innomotics
SKU: 1LE0043-1AC4
Availability: InStock

SKU: 1LE0043-1AC4

Flow Line Motors

Cast Iron Flow Line motor, 1.5 kW, IE3, 950 rpm, frame 100 L

Rated Power

1.5 kW

Sound Pressure Level

49 dB(A)

Frame Size

100 L

Innomotics is part of Siemens Group. We respond to quote requests within 4 business hours.

Electrical

Rated Power	1.5 kW
Rated Speed	950 rpm
Efficiency Class	IE3
Efficiency at 100% Load	82.5 %
Efficiency at 75% Load	84.1 %
Efficiency at 50% Load	82.9 %
Power Factor	0.74
Rated Current	15.1 A
Rated Torque	3.55 Nm
Starting Current Ratio (Ist/In)	5.5
Starting Torque Ratio (Tstart/Tn)	2.5
Maximum Torque Ratio (Tmax/Tn)	3.5

Environmental

Sound Pressure Level	49 dB(A)
Sound Power Level	61 dB(A)

Mechanical

Frame Size	100 L
Enclosure Material	Cast Iron
Weight	41 kg

Detailed Description

Innomotics 1LE0043-1AC4 Flow Line motor with cast iron enclosure. IE3 efficiency class, rated power 1.5 kW at 950 rpm. Frame size 100 L. Efficiency 82.5% at full load. Rated current 15.1 A. Weight 41 kg.
