Innomotics GP 1LE5004 4.0kW 6P

SKU: 1LE5004-1CC2
Innomotics SD — Next Generation (1LE5)

Motor Next Gen IE4: 4.0 kW. 984 rpm, Frame 132M, Eff. 89.5%. IP55.

Rated Power 50Hz
4.0 kW
Degree of Protection
IP55
Frame Size
132M

Innomotics is part of Siemens Group. We respond to quote requests within 4 business hours.

Electrical

Rated Power 50Hz 4.0 kW
Rated Power 60Hz 132.0 kW
Rated Speed 984 rpm
Rated Torque 39.0 Nm
Number of Poles 6
Rated Current 9.0 A

Environmental

Degree of Protection IP55
Insulation Class F (155)
Cooling Method IC411 / IC418

Mechanical

Frame Size 132M
Weight (IM B3) 60.0 kg
Moment of Inertia 0.06 kgm2

Performance

Efficiency 4/4 Load 89.5 %
Efficiency 3/4 Load 89.7 %
Efficiency 2/4 Load 88.6 %
Power Factor 0.72

Detailed Description

GP Motors new generation aluminum IE4. Digital Twin e Smart Motor. Article 1LE5004-1CC2. Rated power 4.0 kW at 50 Hz. Speed 984 rpm. Frame size 132M. Efficiency 89.5% at rated load. Degree of protection IP55. Insulation class F.
